pm::ListMatrix< TVector > Class Template Reference

List of row vectors. More...

Inheritance diagram for pm::ListMatrix< TVector >:

Collaboration diagram for pm::ListMatrix< TVector >:

Public Member Functions
	ListMatrix ()
	create as empty
	ListMatrix (int r, int c)
	create matrix with r rows and c columns, initialize all elements to 0
template<typename Iterator >
	ListMatrix (int r, int c, Iterator src)
ListMatrix &	operator= (const ListMatrix &other)
void	swap (ListMatrix &M)
void	resize (int r, int c)
	Resize to new dimensions, added elements initialized with default constructor.
void	clear ()
	Truncate to 0x0 matrix.
int	rows () const
	the number of rows of the matrix
int	cols () const
	the number of columns of the matrix
template<typename TVector2 >
row_list::iterator	insert_row (const typename row_list::iterator &where, const GenericVector< TVector2 > &v)
	Insert a new row at the given position: before the row pointed to by where.
void	delete_row (const typename row_list::iterator &where)
	Delete the row pointed to by where. Be aware that the iterator becomes void after the removal unless rescued in good time (with postincrement or postdecrement).
void	swap (GenericMatrix< TMatrix2, TVector::element_type > &m)
void	fill (const E2 &x)
std::enable_if< compatible_symmetry_types< TMatrix2 >), top_type & >::type	operator+= (const GenericMatrix< TMatrix2 > &m)
	adding a GenericMatrix
std::enable_if< compatible_symmetry_types< TMatrix2 >), top_type & >::type	operator-= (const GenericMatrix< TMatrix2, TVector::element_type > &m)
	subtracting a GenericMatrix
top_type &	operator*= (const Right &r)
	multiply with an element
std::enable_if< is_expandable_by< TMatrix2 >), top_type & >::type	operator/= (const GenericMatrix< TMatrix2 > &m)
	append the rows of a GenericMatrix
std::enable_if< is_expandable_by< TVector >), top_type & >::type	operator/= (const GenericVector< TVector > &v)
	append a GenericVector as a row
std::enable_if< isomorphic_types< TVector::element_type, Right >::value, top_type & >::type	div_exact (const Right &r)
	divide by an element
std::enable_if< is_expandable_by< TMatrix2 >), top_type & >::type	operator|= (const GenericMatrix< TMatrix2 > &m)
	append the columns of a GenericMatrix
std::enable_if< is_expandable_by< TVector >), top_type & >::type	operator|= (const GenericVector< TVector > &v)
	append a GenericVector as a column
IndexedSlice< ConcatRows< unwary_t< ListMatrix< TVector > > > &, series >	diagonal (int i=0)
IndexedSlice< ConcatRows< unwary_t< ListMatrix< TVector > > > &, series >	anti_diagonal (int i=0)

Detailed Description

template<typename TVector>
class pm::ListMatrix< TVector >

List of row vectors.

A list of row vectors. The implementation is based on std::list. It can be parameterized with any persistent vector type.

Constructor & Destructor Documentation

template<typename TVector >

template<typename Iterator >

pm::ListMatrix< TVector >::ListMatrix ( int  r, int  c, Iterator  src  )

inline

Create a matrix with given dimensions. Elements are initialized from an input sequence. Elements are assumed to come in the row order.

Member Function Documentation

IndexedSlice<ConcatRows<unwary_t<ListMatrix< TVector > > >&, series> pm::GenericMatrix< ListMatrix< TVector > , TVector::element_type >::anti_diagonal ( int  i = 0 )

inlineinherited

Parameters

i==0	main anti-diagonal; i>0: i-th diagonal below the main; i<0: (-i)-th above the main

IndexedSlice<ConcatRows<unwary_t<ListMatrix< TVector > > >&, series> pm::GenericMatrix< ListMatrix< TVector > , TVector::element_type >::diagonal ( int  i = 0 )

inlineinherited

Parameters

i==0	main diagonal; i>0: i-th diagonal below the main; i<0: (-i)-th above the main

void pm::GenericMatrix< ListMatrix< TVector > , TVector::element_type >::fill ( const E2 &  x )

inlineinherited

Fill with given value without changing the dimensions. x can be of arbitrary type assignable to the type E2.

template<typename TVector >

ListMatrix& pm::ListMatrix< TVector >::operator= ( const ListMatrix< TVector > &  other )

inline

Persistent matrix objects have after the assignment the same dimensions as the right hand side operand. Alias objects, such as matrix minor or block matrix, cannot be resized, thus must have the same dimensions as on the right hand side.

template<typename TVector >

void pm::ListMatrix< TVector >::swap ( ListMatrix< TVector > &  M )

inline

Exchange the contents of two matrices in a most efficient way. If at least one non-persistent object is involved, the operands must have equal dimensions.

void pm::GenericMatrix< ListMatrix< TVector > , TVector::element_type >::swap ( GenericMatrix< TMatrix2, TVector::element_type > &  m )

inlineinherited

Exchange the contents of two matrices in a most efficient way. If at least one non-persistent object is involved, the operands must have equal dimensions.

---

The documentation for this class was generated from the following file:

• lib/core/include/ListMatrix.h
